Finder Type 20.22 LATCHING RELAY 2NO 16A

Description

Modular step relays, 35 mm rail (EN 60715) mount, Double phase switch 2 NO, 16 A, AgNi, AC coil, 12 V, operating from 10.2 to 13.2 V, rated power 6.5 VA, resistance 7.5 Ω, consumption 550 mA, ambient temperature from -40 to +40 °C

Available variations:
– Modular step relay, 16A, with 2 NO single-pole contacts, 2-step. For direct mounting on 35mm rail (EN 60715). One module width 17.4 mm, Test button and mechanical indicator, AC or DC coil.
– Modular step relay, 16A, with 2 NO single-pole contacts, 2-step. For direct mounting on 35mm rail (EN 60715). One module width 17.4 mm, Test button and mechanical indicator, AC or DC coil.
– Modular step relay, 16A, with 2 NO single-pole contacts, 2-step. For direct mounting on 35mm rail (EN 60715). One module width 17.4 mm, Test button and mechanical indicator, AC or DC coil.
– Modular step relay, 16A, with 2 NO single-pole contacts, 2-step. For direct mounting on 35mm rail (EN 60715). One module width 17.4 mm, Test button and mechanical indicator, AC or DC coil.
– Modular step relay, 16A, with 2 NO single-pole contacts, 2-step. For direct mounting on 35mm rail (EN 60715). One module width 17.4 mm, Test button and mechanical indicator, AC or DC coil.

Available models:

• 20.22-012-AC: LATCHING RELAY 2NO 16A,12VAC COIL
• 20.22-012-DC: LATCHING RELAY 2NO 16A,12VDC COIL
• 20.22-024-AC: LATCHING RELAY 2NO 16A, 24VAC COIL
• 20.22-024-DC: LATCHING RELAY 2NO 16A, 24VDC COIL
• 20.22-230-AC: LATCHING RELAY 2NO 16A, 230VAC COIL
