Finder Type 26.03 STEP RELAY, 1 NO+1 NC 10A@250VAC

Description

Step relays, Screw terminals, Double phase switch 1 NC + 1 NO, 10 A, AC coil, 12 V, operating from 9.6 to 13.2 V, rated power 4.5 VA, resistance 17 Ω, consumption 370 mA, ambient temperature from -40 to +40 °C

Available variations:
– Type 26.03 Electromechanical step relay with electrically separate coil and contact circuits. Double phase switch 1 NO + 1 NC (SPST-NO + SPST-NC). AC coil. Suitable for panel or recessed mounting.
– Type 26.03 Electromechanical step relay with electrically separate coil and contact circuits. Double phase switch 1 NO + 1 NC (SPST-NO + SPST-NC). AC coil. Suitable for panel or recessed mounting.
– Type 26.03 Electromechanical step relay with electrically separate coil and contact circuits. Double phase switch 1 NO + 1 NC (SPST-NO + SPST-NC). AC coil. Suitable for panel or recessed mounting.

Available models:

• 26.03-012-AC: STEP RELAY, 1 NO+1 NC 10A@250VAC, 12VAC COIL
• 26.03-024-AC: STEP RELAY, 1 NO+1 NC 10A@250VAC, 24VAC COIL
• 26.03-230-AC: STEP RELAY, 1 NO+1 NC 10A@250VAC, 230VAC COIL
