MasterINPUT – SSR – Relay interface modules, Screw terminal, 1 pole, 6 A, Output version, SSR 6 A – 24 V DC, AC/DC supply version, nominal voltage 24 V, operating from 19.2 to 26.4 V (AC)/(DC), rated power 0.4 VA (AC) / 0.3 W (DC), consumption 17.5 mA (AC) and 17.5 mA (DC), must drop-out voltage 2.4 V (AC)/(DC), ambient temperature from -20 to +70 °C
Available variations:
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
Available models:
39.40-024-DC: MasterINPUT SSR 24VAC/DC, 6A@24VDC LOAD, 3 TERMINAL INPUT
39.40-230-AC: MasterINPUT SSR 230VAC, 2A@240VAC LOAD, 3 TERMINAL INPUT
39.40-230VAC/230VAC: MasterINPUT SSR 230VAC, 2A@240VAC LOAD, 3 TERMINAL INPUT
39.40-24VDC/230VAC: MasterINPUT SSR 24VDC, 2A@240VAC LOAD, 3 TERMINAL INPUT
Finder Type 39.40 MasterINPUT SSR 24VAC/DC, 6A@24VDC LOAD, 3 TERMINAL INPUT
Description
MasterINPUT – SSR – Relay interface modules, Screw terminal, 1 pole, 6 A, Output version, SSR 6 A – 24 V DC, AC/DC supply version, nominal voltage 24 V, operating from 19.2 to 26.4 V (AC)/(DC), rated power 0.4 VA (AC) / 0.3 W (DC), consumption 17.5 mA (AC) and 17.5 mA (DC), must drop-out voltage 2.4 V (AC)/(DC), ambient temperature from -20 to +70 °C
Available variations:
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
– MasterINPUT SSR is a Relay Interface Modules with screw terminals – solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC and 230 V AC, 1 contact, 35 mm rail (EN 60715) mounting. 6.2 mm wide, designed for interfacing with PLC systems. Version available with Push-in terminals (Type 39.70).
Available models:
